Edelbrock LS3 Victor Jr. Intake Manifold - (LS3-L92 4150)
This race proven Edelbrock Victor Jr. series intake manifold is designed for Gen IV LS engines equipped with LS3/L92 cylinder heads and a 4150 series carburetor. Coupled with the proper camshaft design and valvetrain peripherals, this manifold has an operating between 3,500 - 7,500 RPM, depending on displacement.
The Victor Jr. L92 manifold uses a standard square bore carb flange that is compatible with Holley 4150 series four barrel carburetors. For carb recommendations, contact us via Email.
All LS3/L92 heads are compatible only with a 4.000" and larger cylinder bore diameters. Can also be used with small bore Ballistic LS3 cylinder heads.
- Uses LS3-L76-L92 style individual port O-ring seals
- Recommended intake gasket - Chevrolet Performance 19256623
- Carb pad height = 7.40'' measured from valley cover
- Intake manifold only - hardware and gaskets not included.
PART NUMBER: EDE-28457
