Edelbrock LT1/LT4 EFI Intake Manifold
The Edelbrock Performer RPM Air-Gap LT1/LT4 intake manifolds feature a tunnel-ram design that offers performance increases in the 1500-6500 RPM range. The air-gap design separates the runners from the hot engine oil, resulting in a cooler, denser charge for more power. These manifolds will accept stock or aftermarket fuel rails and include an OEM style throttle body pad that will accept oversized throttle bodies up to 58mm.
This intake is designed specifically to fit 1992-97 GM LT1 engines, and is matched to the Edelbrock Performer LT1 cylinder heads #61909 and #61919. If using OEM cylinder heads, port matching is recommended for optimum performance.
NOTES:
Port exit dimensions: 2.06 '' x 1.15 ''
Recommended intake gaskets: Edelbrock 7243 or Mr. Gasket 135G
Requires 1994-1996 Late Model Fuel rails
1992-93 LT1 Recommended throttle bodies:
Twin 52mm Throttle Body - BBK #1540
Twin 58mm Throttle Body - BBK #1542
1994-97 LT1/LT4 Recommended throttle bodies:
Twin 52mm Throttle Body - Edelbrock #3809 or BBK #1543
Twin 58mm Throttle Body - Edelbrock #3810 or BBK #1544
PART NUMBER: EDE-7107
